PRODUCTS
균일한 분포를 가지는 구형의 기능성 고분자 입자를 제조합니다
|
PRODUCTS
|
PRODUCTS
Advanced Specialty Polymer
Diasphere® Line-up
| Material | Grade | Ave. Particle Size(um) | Refractive Index | Thermal Property 1) | Hardness 2) | |
|---|---|---|---|---|---|---|
|
Acrylic Polymer (PBMA) |
BH-5 |
|
5 | 1.48 | 240℃~260℃ | 10 |
| BH-10 |
|
10 | ||||
|
Acrylic Polymer (PMMA) |
MH-3FHD |
|
3 | 1.49 | 315℃ | 27 |
| MH-4FHD |
|
4 | 320℃ | |||
| MH-5FHD |
|
5 | 322℃ | |||
| MH-5FD |
|
5 | 240℃~260℃ | |||
| MH-10FD |
|
10 | ||||
| MH-15FD |
|
14 | ||||
| MH-20FD |
|
20 | ||||
| MH-25FD |
|
24 | ||||
| MH-30FD |
|
30 | ||||
| MH-40FD |
|
40 | ||||
| MH-50FD |
|
50 | ||||
| MH-60FD |
|
60 | ||||
| MH-70FD |
|
70 | ||||
| MH-80FD |
|
80 | ||||
| MH-100FD |
|
100 | ||||
|
Styrene Polymer (PS) |
MS-3FHC |
|
3 | 1.59 | 310℃ | 25 |
| MS-5FHC |
|
5 | ||||
| MS-10FHC |
|
10 | ||||
| Core/shell type Styrene Polymer in water base (PS) | SNX-200H |
|
0.2 | 1.49 | 295℃ | 25 |
| SNX-400H |
|
0.4 | ||||
| SNX-600H |
|
0.6 | ||||
|
Silicone (PMSQ) |
KS-200 |
|
2 | 1.42 | Over 400℃ | 15 |
| KS-500 |
|
5 | ||||
| KS-1000 |
|
8 |
- 3% Weight Loss by TGA
- 10% Compression Strength, Mpa by MCTM
Diasphere® Line-up
| PMMA | |||||
|---|---|---|---|---|---|
| MH-3FHD | MH-4FHD | MH-5FHD | MH-10FD | MH-15FD | |
| SIZE(㎛) | 3 | 4 | 5 | 10 | 13 |
| SEM Image |
|
|
|
|
|
| PSD |
|
|
|
|
|
- SEM Image : MH-3FHD, 4FHD, 5FHD x 2.0k and 10FD, 15FD x 1.0k
- PSD(Particle Size Distribution) : Coulter Multisizer 4
Diasphere® Line-up
| PMMA | |||||
|---|---|---|---|---|---|
| MH-20FD | MH-25FD | MH-40FD | MH-60FD | MH-80FD | |
| SIZE(㎛) | 20 | 25 | 40 | 60 | 80 |
| SEM Image |
|
|
|
|
|
| PSD |
|
|
|
|
|
- SEM Image : MH-20FD, 25FD x 1.0k and MH-40FD, 60FD, 80FD x 500
- PSD(Particle Size Distribution) : Coulter Multisizer 4, LS 13 320
Diasphere® Line-up
| Styrene | PBMA | Silicone | |||
|---|---|---|---|---|---|
| MS-10FDC | BH-5 | KS-200C | KS-500 | KS-1000 | |
| SIZE(㎛) | 10 | 5 | 2 | 5 | 9 |
| SEM Image |
|
|
|
|
|
| PSD |
|
|
|
|
|
- SEM Image : MS-10FDC, BH-5 x 1.0k and Silicone x 2.0k
- PSD(Particle Size Distribution) : Coulter Multisizer 4
Characteristic of Diasphere® for New Application
New Products
Highly crosslinked Polystyrene core/shell structured nano size particle
| Name | SNX-200H | SNX-400H | SNX-600H |
|---|---|---|---|
| Particle size(nm | 200 | 400 | 600 |
|
SEM Image (15K) |
|
|
|
- Particle size is measured by Malvern Zetasizer
Key Characteristic of Diasphere®
New ProductsMonodispersed PMMA
Shape controlled bead
Biodegradable bead
Special surface treatment bead with several types of material like metal and inorganic by customer’s requirements
